Production Counter · WSM Series

WSM21 Production Counter

2" + 1" Hourly

WSM21 is a compact hourly production counter for individual machines, workstations, and short manufacturing lines. It gives operators an immediate view of current hour count, previous hour count, and time for quick shift review. Its clear 2-inch and 1-inch LED displays make it ideal where output must be monitored continuously without installing a full plant-level jumbo board.

Send Enquiry Manual
Other models in this family
WSM21 Production Counter 2" + 1" Hourly WSM22D Production Counter 2" Shift / Day Counter WSM42D Production Counter 4" + 2" Multi-Period WSM86 Production Counter 8"+6" Jumbo
2" + 1" Hourly WSM21
Key Specifications

At a Glance

Input
Potential Free Contact
Current Hour
2 Inch
Previous Hour
1 Inch
Clock
0.5 Inch
Use
Hourly production tracking
Dimensions
x x x
Technical Specifications

Full Specification Table

ParameterSpecification
ModelWSM21
Input signalPotential Free Contacts
Current Hour Display2 digits, 50 mm 2 inch) high
Previous Hour Display2 digits, 25 mm (1 inch) high
Digital Clock UsageTo synchronize hourly transfer of reading
Clock displayHH : MM, 4 digits, (½ inch) high Hanging enclosure
Dimensionsmm wide * mm high * mm deep
Operating voltage230 V AC; 50 Hz
MS powder coated enclosure
Cast grade non fading acrylic panel
MakeElectro-Med
Resources

Product Documentation

WSM21 Production Counter — Installation Manual

Wiring, setup, field programming guide
