C08 Multi Display
C08 Multi Display
Weighing scale monitor is used to monitor the number of tippings of juice and water. Fully automatic operation and convenience of remote display.
The signal is picked up from tank tippings and the corresponding value is displayed.
All models are also available with both side display feature, which are suitable for hanging in industrial shed.
Display can either be seven segment displays or dot LED display. These displays are suitable for indoor and outdoor applications respectively.
We have the facility to custom build the indicator to include any feature required by the customer.
Overview
• Input: Magnetic Tip Sensor
• Daily / Weekly / Monthly / Seasonal totalizer
• Monitor number of tippings of juice and water tanks
• MS Powder Coated Panel
• Inbuilt battery backup
Features
• Full automatic operation
• Monitor number of tippings of juice and water tanks
• Daily / Weekly / Monthly / Seasonal totalizer
• Inbuilt battery backup
• Both Side Display (Optional)
• Large displays visible from a distance
• Easy connectivity to slave display
Standard Specifications
• Input: Magnetic Tip Sensor
• Type: Jumbo
• Power Supply: 220V 50 Hz
• Color: Red
• Mounting: Wall Mounting
• Panel: MS Powder Coated
Customizable Features (Made to Order)
Applications
• Jumbo Display in plant area
• Control Room Display
Industries
• Sugar Mill
• Engineering sector
• Textile industry
Variant
| Photo | Model | Current Hour | Previous Hour | Current Day Total | Previous Day Total | Season Total | Clock | Cabinet Size |
|---|---|---|---|---|---|---|---|---|
| WSM86 | 2 digits 8 inch high | 2 digits 6 inch high | 6 Digit in separate enclosure | HH:MM 1 inch high | 780 x 450 x 80 mm | |||
| WSM21 | 2 digits 2 inch high | 2 digits 1 inch high | 6 Digit in separate enclosure | HH:MM 0.5 inch high | 144 x 288 x 160 mm | |||
| WSM22D | 2 digits 4 inch high | 2 digits 4 inch high | 3 digits 2 inch high | 3 digits 2 inch high | 7 Digit 2 inch high | HH:MM 2 inch high | 600 x 550 x 80 mm |
